Fluid power symbol drawing template

  • Sale
  • $ 11.25


DESCRIPTION:
The fluid power symbol drawing template is ideal for students who are learning to read symbols and draw schematics. It is also useful for drafts-persons and engineers who need to draw hydraulic schematics but do not draw enough to warrant a computer- based system.

The symbol template enables the user to draw accurate ANSI and ISO fluid power symbols. Along with the symbols, it also has handy numbers and letters, a measuring scale and conversion formulae printed directly on it.

Ask about our private label program. the fluid power symbol drawing template would make a terrific promotional item with your school or company’s name and logo printed directly on it.
